Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution

Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution

تفاصيل المنتج:

مكان المنشأ: قوانغدونغ ، الصين
اسم العلامة التجارية: LEDKING or OEM & ODM
رقم الموديل: (رو-بي 3)91

شروط الدفع والشحن:

الحد الأدنى لكمية: 1
الأسعار: $145-165
افضل سعر اتصل

معلومات تفصيلية
Pixel Pitch: 3.91mm بكثافة بكسل: 65536 نقطة / م 2
تكوين بكسل: 1R1G1B كحد أقصى استهلاك الطاقة: 40W
وزن لوحة: 0.6 كجم حجم مجلس الوزراء: 500 * 1000 مم * 90 مم، 500 * 500 * 90 مم
قرار مجلس الوزراء: 128 نقطة * 256 نقطة ، 128 * 128 نقطة كمية اللوحة: 8 قطع، 4 قطع
توصيل المحور: HUB75-E أفضل زاوية مشاهدة: 170/ 120
مصدر طاقة الشاشة: تيار متردد 110 فولت/220 فولت - 5 فولت 60 أمبير قدرة الطاقة القصوى: 1200 واط/م2
متوسط القوة: 600 واط/م 2 سطوع: 4000 شمعة / م 2
درجة حرارة التشغيل: -20 درجة مئوية ~ 60 درجة مئوية
إبراز:

High Brightness 4000 cd/m2 LED Video Wall,100000 Hours Life Span Digital Display Board,256*128/256*256 Resolution Outdoor LED Display Screen

,

100000 Hours Life Span Digital Display Board

,

256*128/256*256 Resolution Outdoor LED Display Screen

منتوج وصف

Outdoor P3.91 500*500mm Die-Casting Aluminum Rental Advertising Digital Display Board
Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 0
Product Specifications
Module Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Panel Dimension 192mm(W) * 192mm(H) 250mm(W) * 250mm(H) 256mm(W) * 128mm(H)
Pixel pitch 3mm 3.91mm 4mm
Pixel Density 111111 dot/m² 65536 dot/m² 62500 dot/m²
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD1921 SMD1921 SMD1921
Pixel resolution 64 dot * 64 dot 64 dot * 64 dot 64 dot * 32 dot
Max power consumption 30W 40W 32W
Panel weight 0.55KG 0.6KG 0.3KG
Cabinet Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Cabinet size 576mm*576mm*90mm, 768*768*90MM 500*1000mm*90mm, 500*500*90mm 1024mm*768mm*90mm
Cabinet Resolution 192 dot * 192 dot, 256 dot * 256 dot 128 dot * 256 dot, 128*128 dot 256 dot * 192 dot
Quantity of panel 9pcs, 16pcs 8pcs, 4pcs 24pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Die-casting aluminum cabinet Die-casting aluminum cabinet Die-casting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 140/120 170/120 170/120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 1100 W/m² 1200 W/m² 1550 W/m²
Average power 550 W/m² 600 W/m² 780 W/m²
Technical Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/16S 1/16S 1/8S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096*4096*4096 4096*4096*4096 4096*4096*4096
Brightness 4500-5000 cd/m² 4000 cd/m² 5500-6000 cd/m²
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 3-30M 3-30M 4-40M
Operating temperature -10°C~45°C -20°C~60°C -10°C~45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP65 IP65 IP65
>> Most in Kinglight and 3840 refresh rate, if need to change detail and More Pixel Pitch and technical details, feel free to contact us <<
