Indoor Small Pixel Pitch LED Display Screen Full Color P1.538 LED Video Wall for Meeting Room GOB Protect LED Indoor Display
تفاصيل المنتج:
| مكان المنشأ: | قوانغدونغ، الصين |
| اسم العلامة التجارية: | LED King |
| إصدار الشهادات: | CE FCC ISO |
| رقم الموديل: | داخلي P2.9 |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 1 |
|---|---|
| الأسعار: | $279 |
| تفاصيل التغليف: | حالة خشبية |
| وقت التسليم: | 15 يوما |
| شروط الدفع: | تي/تي |
| القدرة على العرض: | حسب احتياجاتك |
|
معلومات تفصيلية |
|||
| نظام التحكم: | نجمة نوفا | مواد مجلس الوزراء: | يموت الألومنيوم |
|---|---|---|---|
| حجم الخزانة: | 640*480mm | حجم الوحدة: | 250*250mm |
| معدل المسح: | 1/52 ثانية | عمر: | 100000 ساعة |
| إبراز: | P1.538 indoor LED display,GOB protect LED video wall,full color meeting room LED screen,GOB protect LED video wall,full color meeting room LED screen |
||
منتوج وصف
| Module Size | 320mm(W)*160mm(H) |
|---|---|
| Pixel Pitch | 1.538 mm |
| Pixel Density | 422,500 dot/㎡ |
| Pixel Configuration | 1R1G1B |
| LED Specification | SMD1212 |
| Pixel Resolution | 208 dot*104 dot |
| Max Power Consumption | 33W |
| Panel Weight | 0.3KG |
| Cabinet Size | 640mm*480mm |
|---|---|
| Cabinet Resolution | 384 dot * 216 dot |
| Quantity of Panel | 6pcs |
| Hub Connecting | HUB75-E |
| Material | Die-casting aluminum cabinet |
| Maintenance Method | Front/Back service |
| Best Viewing Angle | 170/120° |
| Power Supply | AC110V/220V-5V40A |
| Max Power Consumption | 976W/㎡ |
| Average power consumption | 488W/m² |
| Driving IC | ICN1065 |
|---|---|
| Scan Rate | 1/52S |
| Refresh Frequency | 3840-7680HZ/S |
| Display Color | 4096*4096*4096(16bit) |
| Contrast Ratio | 4000:1 |
| Brightness | 600-800 cd/㎡ |
| Life Span | 100000Hours |
| Best Viewing Distance | 1-30M |
| Operating Temperature | -10℃~60℃ |
| Operating Humidity | 10-70% |
| IP Protective Index | IP43 |
- Extremely detailed picture with no graininess upon viewing. High pixel density ensures sharpness and clarity even at close range, completely eliminating the graininess of traditional LED displays.
- Truly seamless splicing maintains complete and unified image integrity without physical seams, providing superior visual immersion compared to DLP and LCD solutions.
- True color reproduction with high color saturation, refresh rate, and grayscale levels delivers vibrant, realistic colors and smooth transitions without water ripple interference.
- Stable, energy-efficient design with front maintenance capability, adjustable brightness, and flexible installation methods suitable for various high-end indoor applications.
Command and Control Centers: Used in locations requiring 24/7 operation and high-density information visualization, such as public security, emergency response, and military sectors for displaying GIS maps, surveillance videos, and data screens.
Broadcast and Television Studios: Serves as large background screens for news and variety shows, offering true-to-life colors without moiré patterns or water ripples during camera photography.
High-End Conference and Auditoriums: Replaces traditional projectors in boardrooms and auditoriums, supporting HD video playback and seamless display of presentations and documents.
Commercial Display and Brand Spaces: Applied in showrooms, retail stores, and museums for corporate branding, product promotion, and interactive experiences with stunning visual impact.
